Description
A123’s high-performance Nanophosphate® lithium iron phosphate (LiFePO4) battery technology delivers high power and energy density combined with excellent safety performance and extensive life cycling in a lighter weight, more compact package. The cells have low capacity loss and impedance growth over time as well as high usable energy over a wide state of charge (SOC) range, allowing our systems to meet end-of-life power and energy requirements with minimal pack oversizing.
-Excellent abuse tolerance and superior cycle life from A123's patented Nanophosphate lithium ion Chemistry
-High power with over 2,600W/kg and 5,800 W/L, 10 seconds, 50%SOC
-High usable energy over a wide state of charge (SOC) range
COMMERCIAL SOLUTIONS
Advanced lead acid replacement batteries for: Datacenter UPS, Telecom backup, IT backup, Autonomously guided vehicles (AGVs), Industrial robotics and material handling equipment, Medical devices
GOVERNMENT SOLUTIONS
Military vehicles, Military power grids, Soldier power, Directed energy
GRID SOLUTIONS
Versatile, flexible and proven storage solutions for the grid
TRANSPORTATION SOLUTIONS
Hybrid, plug-in hybrid and electric vehicle battery systems for: Commercial vehicles, Off-highway vehicles, Passenger vehicles
Item | Parameter |
Cell Dimensions | φ26*65mm |
Cell Weight | 76g |
Cell Capacity(nominal/minimum) (0.5C Rate) | 2.5/2.4Ah |
Voltage(nominal) | 3.3V |
Internal Impedance (1kHz AC typical) | 6mΩ |
Power | 2600W/kg |
Recommended Standard Charge Method | 2.5A to 3.6V CCCV, 60 min |
Recommended Fast Charge Method to 80% SOC | 10A to 3.6V CC, 12 min |
Maximum Continuous Discharge | 50A |
Maximum Pulse Discharge (10 seconds) | 120A |
Cycle Life at 20A Discharge, 100% DOD | ＞1000 cycles |
Operating Temperature | -30℃ to 55℃ |
Storage Temperature | -40℃ to 60℃ |
