Description
1.High Energy Density
2.Long Cycle Life
3.Good performance at high/low temperature
4.High-rate continuous discharge
Item | Specifications | Remark |
Chemical | LiFePO4 | |
Dimension | 224(mm)*9.8(mm)*90.25(mm) | 25%SOC |
Tab width | 15±0.1mm | |
Tab distance | 30±1mm | |
Positive tab (aluminum) thickness | 0.2±0.01mm | |
Negative tab (nickel plated copper) thickness | 0.15±0.01mm | |
Weight | 0.39kg | |
Capacity | ≥21.7Ah | 2.7~3.65V,0.5C/0.2C, @RT |
Nominal voltage | 3.2V | At 25℃ |
Operating voltage range | 2.5-3.65V | At 25℃ |
Outgoing voltage | 3.275~3.3V | At 25℃ |
Outgoing SOC | 25% | |
ACIR | ≤1.8mΩ | 25±3℃,1kHz |
Standard charging current | 0.2C | At 25℃ |
Max. continuous charging current | 1C | At 25℃, ≤60%SOC |
Standard discharging current | 0.2C | At 25℃ |
Max. continuous discharging current | 1C | At 25℃ |
Operating temperature range(charge) | -20~60℃ | Ambient Temperature |
Operating temperature range(discharge) | -20~60℃ | Ambient Temperature |
Cycle life | ≥2500cls@80%SOH | 0.5C/1.0C @25℃ |
≥1200cls@80%SOH | 0.5C/1.0C @45℃ |
